Anyone on here play around with VCDS coding on the Q3 yet? I'm interested to see what is possible to enable via some simple coding changes.

For those of you that don't know what I'm referring to: http://www.ross-tech.com/vag-com/index.html

For example, on my 2011 Volkswagen GTI I was able to enable a gauge sweep when the ignition is turned on, rolling up/down the windows via key fob, disabling the daytime running lights, and enabling the European headlight switch for city lights and rear fogs. There are tons of other possibilities hidden within this program, I'm excited to see if anyone on here finds any hidden gems :) I might be investing in a cable soon for both our cars, so I'll update if I do & find anything neat!


·
Premium Member
Joined
·
2,484 Posts
Your existing cable - if the current one, and I believe it should be for your VW - will work fine. I am pretty versed in VAG-COM and have a good friend who is a programmer for RossTech, so will be exploring soon as I get my Q3 to play with ...

I've done many codes on my Audis so far and look forward to the same and more for the Q - stay tuned -

  • Like
Reactions: buddha

·
Registered
Joined
·
158 Posts
Subscribed, really interested in what exactly can be accessed. Is there any risk of voiding warranty or the like from playing around in VCDS?


·
Registered
Joined
·
142 Posts
Here's a full autoscan I did on my new Q3.
Just in case it's of interest to you :)

Thursday,11,September,2014,15:32:05:09724
VCDS -- Windows Based VAG/VAS Emulator
VCDS Version: 12.12.3.0 (x64)
Data version: 20140822


VIN: WAUZZZ8U2ER123456 License Plate: AA00AAA
Mileage: 130.7 Repair Order:



--------------------------------------------------------------------------------
--------------------------------------------------------------------------------


Chassis Type: 8U (8U0)
Scan: 01 02 03 08 09 10 15 16 17 19 22 25 42 44 46 52 53 55 56 5F
62 72

VIN: WAUZZZ8U2ER123456

01-Engine -- Status: OK 0000
02-Auto Trans -- Status: OK 0000
03-ABS Brakes -- Status: OK 0000
04-Steering Angle -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
22-AWD -- Status: OK 0000
25-Immobilizer -- Status: OK 0000
42-Door Elect, Driver -- Status: OK 0000
44-Steering Assist -- Status: OK 0000
46-Central Conv. -- Status: OK 0000
52-Door Elect, Pass. -- Status: OK 0000
53-Parking Brake -- Status: OK 0000
55-Xenon Range -- Status: OK 0000
56-Radio -- Status: OK 0000
5F-Information Electr. -- Status: OK 0000
62-Door, Rear Left -- Status: OK 0000
72-Door, Rear Right -- Status: OK 0000

-------------------------------------------------------------------------------
Address 01: Engine (J623-CFGC) Labels: 03L-906-018-CFF.clb
Part No SW: 03L 906 018 PH HW: 03L 906 018 ES
Component: R4 2,0L EDC H28 6636
Revision: 41H28--- Serial number:
Coding: 00250012043701080000
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_ECM20TDI01103L906018PH 003006
ROD: EV_ECM20TDI01103L906018PH.rod
VCID: 7F06CC35E6D880E6E27-802A

No fault code found.
Readiness: 0 0 0 0 0

-------------------------------------------------------------------------------
Address 02: Auto Trans (J743) Labels: 0BH-927-711.clb
Part No SW: 0BH 300 012 A HW: 0BH 927 711 C
Component: DSG DQ500-7A H08 2233
Revision: 00H08V01
Coding: 0014
Shop #: WSC 00000 000 00000
ASAM Dataset: EV_TCMDQ500021 001001
ROD: EV_TCMDQ500021_AU21.rod
VCID: 21422A4D30EC1616B43-8074

No fault code found.

-------------------------------------------------------------------------------
Address 03: ABS Brakes Labels: None
Part No SW: 5N0 614 109 BA HW: 5N0 614 109 BA
Component: J104 C6 450M VD06 0160
Revision: --H07--- Serial number: 00000008231167
Coding: 0056717
Shop #: WSC 00049 770 00153
VCID: 6BDE08654AA00C465EF-803E

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC Labels: 8P0-820-043.lbl
Part No SW: 8U0 820 043 E HW: 8U0 820 043 E
Component: E87 Klimavoll 0100
Revision: 00H04000 Serial number: 8U0820043E
Shop #: WSC 00000 000 00000
VCID: 336ED0055210948656F-8066

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels: 8X0-907-063.clb
Part No SW: 8X0 907 063 R HW: 8X0 907 063 R
Component: BCM PQ35 M 113 0811
Revision: AD113811
Coding: 0E000A2FA805F1C0201841C02104094C53FF84AA216F912BE408878400C5
Shop #: WSC 00049 770 00008
VCID: 4B9EA8E5EAE0EC463EF-801E

Subsystem 1 - Part No SW: 8U2 955 119 HW: 8U2 955 119
Component: WWS316 140515 H37 0085
Coding: 0047F7

Subsystem 2 - Part No SW: 8U0 955 559 B HW: 8U0 955 559 B
Component: G397_RLFS H06 0002
Coding: 02006E

Subsystem 3 - Part No: 8X0 951 177
Component: DWA-Sensor H0 H01 0020

Subsystem 4 - Part No: 1K0 951 605 C
Component: LIN BACKUP HO H05 1501

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels: 8X0-919-475.clb
Part No SW: 8X0 919 475 N HW: 4H0 919 475 AG
Component: PARKHILFE 8K H01 0050
Revision: 11001001 Serial number: 61061416201043
Coding: 88C305
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_EPHVA18AU21X0000 003006
ROD: EV_EPHVA18AU21X0000.rod
VCID: 51A2BA8D00CCC696443-8004

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels: 8X0-959-655.clb
Part No SW: 8U0 959 655 B HW: 8U0 959 655 B
Component: AirbagVW-AU10 H09 0520
Serial number: 003LRR08GZ5D
Coding: 30393132313030303030554A305238553053
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_AirbaAU10SMEAU316 001005
ROD: EV_AirbaAU10SMEAU316.rod
VCID: 468899D1F982112EE11-8013

Crash sensor for side airbag; driver side:
Subsystem 1 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Fahr.V H02 ----
Serial number: 3496KSME0648232FZZZ-

Crash sensor for side airbag; passenger side:
Subsystem 2 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Beif.V H02 ----
Serial number: 3506KSME7F67232FZZZ2

Crash sensor for side airbag; rear driver side:
Subsystem 3 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Fahr.H H02 ----
Serial number: 3516KSME6361232FZZZR

Crash sensor for side airbag; rear passenger side:
Subsystem 4 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Beif.H H02 ----
Serial number: 3526KSME2977232FZZZ.

Crash sensor for front airbag; driver side:
Subsystem 5 - Part No SW: 8U0 959 651 HW: 8U0 959 651
Component: F.Sens.Fahr H02 ----
Serial number: 3555USME520D5C2DZZZB

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels: 8X0-953-569.clb
Part No SW: 8X0 953 521 D HW: 5K0 953 569 AE
Component: LENKS.MODUL 016 0140
Revision: FF010018 Serial number: 20140616101321
Coding: 1894204000
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_SMLSNGVOLWSXS A01004
ROD: EV_SMLSNGVOLWS.rod
VCID: 3D7AF63DAC5452F6B0B-8068

Multi Function Steering Wheel Control Module:
Subsystem 1 - Part No SW: 8U0 951 528 H HW: 8U0 951 528 H
Component: E221 - MFL H08 0010

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels: 8X0-920-xxx-17.clb
Part No SW: 8U0 920 990 E HW: 8U0 920 990 E
Component: KOMBI_COLOUR H01 0240
Serial number: 00000000000000
Coding: 42CF01
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_Kombi_UDS_VDD_AU10 A04399
ROD: EV_Kombi_UDS_VDD_AU10.rod
VCID: 3F868C35A65840E6A27-806A

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels: 8X0-907-468.clb
Part No SW: 8U0 907 468 AE HW: 8U0 907 468 J
Component: GAT 4CAN 2L M H13 0072
Revision: 1R150039 Serial number: 3941R1452503D8
Coding: FBCF1A5A050B05610353
Shop #: WSC 00049 770 00118
VCID: 850ADEDD0C045A3628B-80D0

Subsystem 1 - Part No SW: 8U0 959 591 HW: 8V3 959 591
Component: J245 PS11.018 H02 0007
Coding: 901E00

Subsystem 2 - Part No SW: 1K0 915 181 H HW: 1K0 915 181 A
Component: J367-BDM H07 0180

Subsystem 3 - Part No SW: 8U0 959 591 HW: 8V3 959 591
Component: J394 PS11.018 H02 0007
Coding: 801E00

Subsystem 4 - Part No SW: 8K0 959 663 HW: 8K0 959 663
Component: J532_DCDCStab H17 0042

No fault code found.

-------------------------------------------------------------------------------
Address 22: AWD (J492) Labels: None
Part No SW: 0AY 907 554 F HW: 0AY 907 554 F
Component: Haldex4Motion H52 7521
Serial number: HA1-00023.05.14
Coding: 0001
Shop #: WSC 00049 770 00153
ASAM Dataset: EV_AllWheelContrHA1VW37X 002001
ROD: EV_AllWheelContrHA1VW37X_AU21.rod
VCID: 4E98A1F111F2D96E591-801B

No fault code found.

-------------------------------------------------------------------------------
Address 25: Immobilizer (J334) Labels: 5K0-920-xxx-25.clb
Part No SW: 8U0 920 990 E HW: 8U0 920 990 E
Component: IMMO H01 0240
Serial number:
Coding: 000002
Shop #: WSC 00049 770 00118
ASAM Dataset: EV_Immo_UDS_VDD_AU10 A04113
ROD: EV_Immo_UDS_VDD_AU10.rod
VCID: 3F868C35A65840E6A27-806A

No fault code found.

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels: 8X0-959-793.clb
Part No SW: 8X0 959 793 H HW: 8X0 959 793 H
Component: TSG FA H10 0415
Revision: -------- Serial number: --------------
Coding: 011E06200001000000
Shop #: WSC 00049 770 00153
VCID: 52A0B5810DCABD8E7D9-8007

No fault code found.

-------------------------------------------------------------------------------
Address 44: Steering Assist Labels: None
Part No: 5N0 909 144 R
Component: EPS_ZFLS Kl. 296 3501
Revision: 00H22000
Shop #: WSC 00049 770 00153
VCID: 40848FC913A63F1EDBD-8015

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels: 8X0-959-792.clb
Part No SW: 8X0 959 792 H HW: 8X0 959 792 H
Component: TSG BF H10 0415
Revision: -------- Serial number: --------------
Coding: 011E06200001000000
Shop #: WSC 00049 770 00153
VCID: 51A2BA8D08CCC696443-8004

No fault code found.

-------------------------------------------------------------------------------
Address 53: Parking Brake Labels: 3AA-907-801.clb
Part No SW: 3AA 907 801 J HW: 3AA 907 801 J
Component: J540 EPB4 VW-63206 0012
Revision: H19 Serial number: 00000000079643
Coding: 0025166
Shop #: WSC 00049 770 00153
VCID: 3874E7294B7677DE63D-806D

No fault code found.

-------------------------------------------------------------------------------
Address 55: Xenon Range (J431) Labels: 8X0-907-357.clb
Part No SW: 8X0 907 357 C HW: 8X0 907 357 B
Component: ****LWR12**** H02 0020
Serial number: 140606-0002-070
Coding: 1157A41010002500
Shop #: WSC 00049 770 00153
ASAM Dataset: EV_HeadlRegulBasic 005001
ROD: EV_HeadlRegulBasic.rod
VCID: 428085C1D5AA2D0ECD9-8017

No fault code found.

-------------------------------------------------------------------------------
Address 56: Radio (R) Labels: Redir Fail!
Part No SW: 4G0 035 061 N HW: 4G0 035 061
Component: Radio U DAB H60 0139
Revision: AB001007 Serial number: 109F50E7934298
Coding: 010105020100000002
Shop #: WSC 00049 770 00153
VCID: 285437695BD6E75EF3D-807D

No fault code found.

-------------------------------------------------------------------------------
Address 5F: Information Electr. (J794) Labels: None
Part No SW: 8U0 035 666 J HW: 8U0 035 666 D
Component: H-BN-EU H46 0814
Revision: -------- Serial number: 199F/0EB002147
Coding: 0E010106000AE1E90180033600000001E00100020000000000
Shop #: WSC 00049 770 00118
VCID: 41828ACDD8AC3616D43-8014

Subsystem 1 - Part No: 8R0 060 884 BT
Component: EUR 2014 1903

Subsystem 2 - Part No SW: 8U0 919 604 A HW: 8U0 919 604 A
Component: DU High AU316 H42 0018

Subsystem 3 - Part No: 8R0 060 961 G
Component: CD-Database 5950

No fault code found.

-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388) Labels: None
Part No SW: 8X0 959 795 C HW: 8X0 959 795 C
Component: TSG HL H07 0415
Revision: -------- Serial number: --------------
Coding: 010E06200001000000
Shop #: WSC 00049 770 00153
VCID: 4FA6BCF51EF8D066527-801A

No fault code found.

-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389) Labels: None
Part No SW: 8X0 959 795 C HW: 8X0 959 795 C
Component: TSG HR H07 0415
Revision: -------- Serial number: --------------
Coding: 010E06200001000000
Shop #: WSC 00049 770 00153
VCID: 4FA6BCF51EF8D066527-801A

No fault code found.

End ---------------------------------------------------------------------


·
Premium Member
Joined
·
2,484 Posts
Subscribed, really interested in what exactly can be accessed. Is there any risk of voiding warranty or the like from playing around in VCDS?
Depends on your dealer, what you're messing around with and how much you know about what you're doing. Basically, without some care, you CAN mess some things up, Audi can fix it, but they may not be very happy about it AND they may/can charge you for the fix...

But most things are reasonably safe, even though Audi may undo some/all of them each time THEY scan/code your car. My dealer knows me, knows/saves my changes and keeps them for me. I have a substantially re-coded ECM and they know to NOT scan or code it.


·
Premium Member
Joined
·
2,484 Posts
@CocoPops - interesting : where's a couple modules in the detail, i.e. 4 - Steering Angle - Drive Select and 46 - Central Conv - BCM? Seems they're fine but the detail blocks have disappeared in your scan log...


·
Registered
Joined
·
142 Posts
Pass.

Not sure why, that was just a full autoscan.

I'll try and see what happens if I run it again.


·
Premium Member
Joined
·
2,484 Posts
Thanks - btw, Misano is such a GREAT color - please post a few pics in your garage. My good friend has a Misano RS6(C5) and it's so perfect for that large sedan - saloon. And, I just drove a new S3 in Austin that Audi is raffling off this weekend at COTA (yes I bought tickets of course), and it looks good too - would love a peek at your car...


·
Registered
Joined
·
142 Posts


A quick pic :) Taken this weekend when I happened to park next to another Q3.


·
Premium Member
Joined
·
2,484 Posts
Oh man - GREAT pic - thanks much :D:D

Just love it - !!!


·
Registered
Joined
·
142 Posts
@CocoPops - interesting : where's a couple modules in the detail, i.e. 4 - Steering Angle - Drive Select and 46 - Central Conv - BCM? Seems they're fine but the detail blocks have disappeared in your scan log...
I've sent the autoscan to RossTech support so they can take a look, they seem interested as the Q3 has a number of missing labels in the autoscan.


·
Premium Member
Joined
·
2,484 Posts
Great - I'm especially interested in a detail scan of your module 46 as I will need to know a few channels' code for my new car when it arrives. I will install eCode rear tail lamps and this code is different for us than you (looks like you're in Europe, but can't quite read your plate country) to make the signal/stop lamps work correctly. I'm hoping to find the correct access codes (anybody? - Security Access and Personalization Code) to the module to allow channel adaptations: then I can apply your channel codes to my BCM2.

Have you tried to scan just module 46 rather than a whole car auto scan?


·
Registered
Joined
·
142 Posts
I'm in UK :)

However, I do have a reply from RossTech regarding Module 46...
Like other Golf 6 based vehicles, there is no real 46 module. We believe it is still shown in the Gateway Installation list for some sort of internal compatibility reasons but all of the duties that 46 would historically perform, are now handled by 09.
Anyway, I'm in Milan until Thursday, so I am sending them a full debug autoscan on Friday and I'll try and get the info you require from Module 9 as per above.


·
Premium Member
Joined
·
2,484 Posts
Interesting : since in the larger platforms, 09 is BCM1 and 46 is BCM2, it may make some sense for this platform to really just have one. Then that's where I'll want to poke around for what I need. Somewhere in the adaptation channels in that BCM is where I'll find the correct bit code to separate the stop and signal lights to make my eCode rear LEDs work right. Luckily there's only four channels I'll need to revise, but perhaps amongst about 150 ... I am hopeful that the channels I'm looking for will be similarly numbered to those in my B8, hence easy to find - or I get some good advice from an Audi tech ;)


·
Registered
Joined
·
142 Posts
I submitted a full debug level2 scan to RossTech over the weekend, so fingers crossed they can sort the label files for the Q3.


·
Premium Member
Joined
·
2,484 Posts
Great - many thanks for your efforts and support -


·
Registered
Joined
·
2 Posts
Q3 TPMS activation

Hi all,

im looking for a little help here? I have a 2013 model and made the mistake of not adding TPMS as an option when building my car. I now understand that TPMS is standard across all Q3 models?

From what i have read the system the Q3 uses is based on readings from the ABS sensors from each wheel.

So far i have managed to turn on the visual side of TPMS, which activates the warning messages on the DIS on the dashboard! This indicates that the TPMS has a failure. I have not been able to go any further with this as I cannot find an option in the green menu to turn on the TPMS function in the CAR menu for the MMI screen. Also I am unable to make the coding changes required on the ABS module as it requires the security code of my car to do it, from what I understand only AUDI have these codes!

Any help would be great


·
Premium Member
Joined
·
2,484 Posts
The early TPMS has sensors (transmitters) in each wheel/tire that send signals to the ABS sensors for analysis and virtual differential pressure determination. In addition to the Vag-Com mods you're trying to make, you'd need the matching hardware too, at about USD 40-50 per wheel.

The current car uses a different - second generation vibration detection analysis to accomplish the same thing and I'm not sure what physical hardware is necessary to support it. I'll check and post here shortly ...


·
Premium Member
Joined
·
2,484 Posts
The Q3 uses the newest NIRA Dynamics software-based TPMS, hence no wheel sensors. It is an indirect system, and with the proper coding MAY be retrofitted to your car if it is not already so equipped. As you note above, there are several levels of coding options within Vag-Com and VCDS. You'll need to obtain both the Security Access and Personalization Key codes to get to the level for adaptations - (I don't have these yet but will keep trying). Then you'll need to know which channels (there are 256 of them, but perhaps only a few, as little as 5-6, need to be changed) and of course, what values to assign (adapt) them to... I'll look for them too.


·
Registered
Joined
·
6 Posts
Hi,

Tried to do same TPMS mod however problem seems to be in ABS module (5N0 614 109 AS): long coding is not active so only that can be altered is a 7 digit value. Tried to add a value of 4096 as read on a German forum but it's not accepted.
Really appreciate some advise. My autoscan below


VCDS -- Windows Based VAG/VAS Emulator
VCDS Version: 12.12.3.0 (x64)
Data version: 20140822


VIN: WAUZZZ8U0ER123456 License Plate: ASASA
Mileage: 10000 Repair Order:



--------------------------------------------------------------------------------
--------------------------------------------------------------------------------


Chassis Type: 8U (8U0)
Scan: 01 03 08 09 10 15 16 17 19 22 25 42 44 46 52 53 55 5F 62 6C
72

VIN: WAUZZZ8U0ER123456

01-Engine -- Status: OK 0000
03-ABS Brakes -- Status: OK 0000
04-Steering Angle -- Status: OK 0000
08-Auto HVAC -- Status: OK 0000
09-Cent. Elect. -- Status: OK 0000
10-Park/Steer Assist -- Status: OK 0000
15-Airbags -- Status: OK 0000
16-Steering wheel -- Status: OK 0000
17-Instruments -- Status: OK 0000
19-CAN Gateway -- Status: OK 0000
22-AWD -- Status: OK 0000
25-Immobilizer -- Status: OK 0000
42-Door Elect, Driver -- Status: OK 0000
44-Steering Assist -- Status: OK 0000
46-Central Conv. -- Status: OK 0000
52-Door Elect, Pass. -- Status: OK 0000
53-Parking Brake -- Status: OK 0000
55-Xenon Range -- Status: OK 0000
5F-Information Electr. -- Status: OK 0000
62-Door, Rear Left -- Status: OK 0000
6C-Back-up Cam. -- Status: Malfunction 0010
72-Door, Rear Right -- Status: OK 0000

-------------------------------------------------------------------------------
Address 01: Engine (J623-CFFB) Labels: 03L-906-018-CFF.clb
Part No SW: 03L 906 018 CM HW: 03L 906 018 ES
Component: R4 2,0L EDC H28 4900
Revision: 41H28--- Serial number:
Coding: 00190012040601080000
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_ECM20TDI01103L906018CM 003004
ROD: EV_ECM20TDI01103L906018CM.rod
VCID: 77FD0D57CE389FA6A59-8022

No fault code found.
Readiness: 0 0 0 0 0

-------------------------------------------------------------------------------
Address 03: ABS Brakes Labels: None
Part No SW: 5N0 614 109 AS HW: 5N0 614 109 AS
Component: J104 C6 450M V4B7 0150
Revision: --H07--- Serial number: 00000007589134
Coding: 0050311
Shop #: WSC 00049 770 00153
VCID: 7CF7127B3F1EBCFEC8B-8029

No fault code found.

-------------------------------------------------------------------------------
Address 08: Auto HVAC Labels: 8P0-820-043.lbl
Part No SW: 8U0 820 043 D HW: 8U0 820 043 D
Component: E87 Klimavoll 0100
Revision: 00H04000 Serial number: 8U0820043D
Shop #: WSC 00000 000 00000
VCID: 326BFC43ADDABA8E527-8067

No fault code found.

-------------------------------------------------------------------------------
Address 09: Cent. Elect. (J519) Labels: 8X0-907-063.clb
Part No SW: 8X0 907 063 N HW: 8X0 907 063 N
Component: BCM PQ35 M 112 0771
Revision: AG112771
Coding: 06000A2CE817F3C0A01841C02100894C57FF84AA216F912BE4088F8400C5
Shop #: WSC 00049 770 00010
VCID: 479DBD97F6582F26159-8012

Subsystem 1 - Part No SW: 8U1 955 119 HW: 8U1 955 119
Component: WWS316 131026 H36 0085
Coding: 0047F7

Subsystem 2 - Part No SW: 8U0 955 559 B HW: 8U0 955 559 B
Component: G397_RLFS H06 0002
Coding: 02006E

Subsystem 3 - Part No: 8X0 951 177
Component: DWA-Sensor H0 H01 0020

Subsystem 4 - Part No: 1K0 951 605 C
Component: LIN BACKUP HO H05 1501

No fault code found.

-------------------------------------------------------------------------------
Address 10: Park/Steer Assist (J446) Labels: 8X0-919-475.clb
Part No SW: 8X0 919 475 M HW: 8X0 919 475
Component: PARKHILFE 4K H03 0051
Revision: 11001001 Serial number: 37031328401121
Coding: 280004
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_EPHVA14AU21X0000 002005
ROD: EV_AU210ParkAssis4K.rod
VCID: 50AF96CB0B16E89E443-8005

No fault code found.

-------------------------------------------------------------------------------
Address 15: Airbags (J234) Labels: 8X0-959-655.clb
Part No SW: 8U0 959 655 B HW: 8U0 959 655 B
Component: AirbagVW-AU10 H08 0520
Serial number: 003LRR06EHVH
Coding: 30353132313030303030554A304C38553053
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_AirbaAU10SMEAU316 001005
ROD: EV_AirbaAU10SMEAU316.rod
VCID: 4683B093F952362EEEF-8013

Crash sensor for side airbag; driver side:
Subsystem 1 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Fahr.V H02 ----
Serial number: 3496KSME41504C29ZZZX

Crash sensor for side airbag; passenger side:
Subsystem 2 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Beif.V H02 ----
Serial number: 3506KSME040A5029ZZZI

Crash sensor for side airbag; rear driver side:
Subsystem 3 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Fahr.H H02 ----
Serial number: 3516KSME3D104F29ZZZ-

Crash sensor for side airbag; rear passenger side:
Subsystem 4 - Part No SW: 5K0 959 351 A HW: 5K0 959 351 A
Component: S.Sens.Beif.H H02 ----
Serial number: 3526KSME41285029ZZZL

Crash sensor for front airbag; driver side:
Subsystem 5 - Part No SW: 8U0 959 651 HW: 8U0 959 651
Component: F.Sens.Fahr H02 ----
Serial number: 3555USME10613226ZZZN

No fault code found.

-------------------------------------------------------------------------------
Address 16: Steering wheel (J527) Labels: 8X0-953-569.clb
Part No SW: 8X0 953 501 B HW: 5K0 953 569 AL
Component: LENKS.MODUL 016 0140
Revision: FF010018 Serial number: 20131114200053
Coding: 1184004000
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_VW360SteerWheelUDS A03004
ROD: EV_VW360SteerWheelUDS.rod
VCID: 3979CB6FB8AC49D693D-806C

Multifunction steering wheel control module:
Subsystem 1 - Part No SW: 8U0 951 528 G HW: 8U0 951 528 G
Component: E221 - MFL H08 0010

No fault code found.

-------------------------------------------------------------------------------
Address 17: Instruments (J285) Labels: 8X0-920-xxx-17.clb
Part No SW: 8U0 920 940 E HW: 8U0 920 940 E
Component: KOMBI_COLOUR H01 0230
Serial number: 00000000000000
Coding: 12CF00
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_Kombi_UDS_VDD_AU10 A04399
ROD: EV_Kombi_UDS_VDD_AU10.rod
VCID: 3A7BD463BDAA42CE9A7-806F

No fault code found.

-------------------------------------------------------------------------------
Address 19: CAN Gateway (J533) Labels: 8X0-907-468.clb
Part No SW: 8U0 907 468 Q HW: 8U0 907 468 G
Component: GAT 4CAN 1L M H13 0063
Revision: 1P120037 Serial number: 3741P13A2202AB
Coding: FBCF1A5A000100610253
Shop #: WSC 00049 770 00119
VCID: 50AF96CB0316E89E443-8005

Subsystem 1 - Part No SW: 1K0 915 181 H HW: 1K0 915 181 A
Component: J367-BDM H07 0180

Subsystem 2 - Part No SW: 8K0 959 663 HW: 8K0 959 663
Component: J532_DCDCStab H17 0042

No fault code found.

-------------------------------------------------------------------------------
Address 22: AWD (J492) Labels: None
Part No SW: 0AY 907 554 F HW: 0AY 907 554 F
Component: Haldex4Motion H52 7521
Serial number: HA1-00021.09.13
Coding: 0001
Shop #: WSC 00049 770 00153
ASAM Dataset: EV_AllWheelContrHA1VW37X 002001
ROD: EV_AllWheelContrHA1VW37X.rod
VCID: 4E9388B31122FE6E56F-801B

No fault code found.

-------------------------------------------------------------------------------
Address 25: Immobilizer (J334) Labels: 5K0-920-xxx-25.clb
Part No SW: 8U0 920 940 E HW: 8U0 920 940 E
Component: IMMO H01 0230
Serial number:
Coding: 000002
Shop #: WSC 00049 770 00119
ASAM Dataset: EV_Immo_UDS_VDD_AU10 A04113
ROD: EV_Immo_UDS_VDD_AU10.rod
VCID: 3A7BD463BDAA42CE9A7-806F

No fault code found.

-------------------------------------------------------------------------------
Address 42: Door Elect, Driver (J386) Labels: 8X0-959-793.clb
Part No SW: 8X0 959 793 K HW: 8X0 959 793 K
Component: TSG FA H10 0415
Revision: -------- Serial number: --------------
Coding: 011E02200000000000
Shop #: WSC 00049 770 00153
VCID: 55A167DF3CF48DB6975-8000

No fault code found.

-------------------------------------------------------------------------------
Address 44: Steering Assist Labels: 5N1-909-144.clb
Part No SW: 5N1 909 144 R HW: 5N1 909 148 J
Component: J500__APA-BS KL.374 1401
Revision: 1BH04841 Serial number: 00132860007401
Coding: 0000258
Shop #: WSC 00049 770 00153
VCID: 4189A38F187C1116DBD-8014

No fault code found.

-------------------------------------------------------------------------------
Address 52: Door Elect, Pass. (J387) Labels: 8X0-959-792.clb
Part No SW: 8X0 959 792 K HW: 8X0 959 792 K
Component: TSG BF H10 0415
Revision: -------- Serial number: --------------
Coding: 011E02200000000000
Shop #: WSC 00049 770 00153
VCID: 54A79ADB370E94BE60B-8001

No fault code found.

-------------------------------------------------------------------------------
Address 53: Parking Brake Labels: 3AA-907-801.clb
Part No SW: 3AA 907 801 H HW: 3AA 907 801 H
Component: J540 EPB4 VW-86594 0010
Revision: H19 Serial number: 00000001582312
Coding: 0025167
Shop #: WSC 00049 770 00153
VCID: 3663C05341B2A6AE7EF-8063

No fault code found.

-------------------------------------------------------------------------------
Address 55: Xenon Range (J431) Labels: None
Part No SW: 8X0 907 357 C HW: 8X0 907 357 B
Component: ****LWR12**** H02 0020
Serial number: 131106-0002-014
Coding: 1157A41010022500
Shop #: WSC 00049 770 00153
ASAM Dataset: EV_HeadlRegulBasic 005001
ROD: EV_HeadlRegulBasic.rod
VCID: 428BAC83D57A0A0EC27-8017

No fault code found.

-------------------------------------------------------------------------------
Address 5F: Information Electr. (J794) Labels: None
Part No SW: 8U0 035 193 C HW: 8U0 035 193 A
Component: RMC Cnct Nav H54 0801
Coding: 01000600028157070823020103010000000000
Shop #: WSC 00049 770 00119
VCID: 3561C75F9CB4ADB6775-8060

Subsystem 1 - Part No SW: 8U0 919 603 HW: 8U0 919 603
Component: DUBasic AU316 H41 0018

No fault code found.

-------------------------------------------------------------------------------
Address 62: Door, Rear Left (J388) Labels: None
Part No SW: 8X0 959 795 C HW: 8X0 959 795 C
Component: TSG HL H07 0415
Revision: -------- Serial number: --------------
Coding: 010E02200000000000
Shop #: WSC 00049 770 00153
VCID: 4FAD95B71E28F7665D9-801A

No fault code found.

-------------------------------------------------------------------------------
Address 6C: Back-up Cam. Labels: None
Part No SW: 8U0 907 441 HW: 8U0 907 441
Component: SG Rueckfahrkamera 0031
Revision: --H09--- Serial number: 525 PA8J3ZH20D
Coding: 1020015
Shop #: WSC 98765 666 38384
VCID: F6E38053813266AE3EF-80A3

1 Fault Found:
03006 - Back-up Camera System not calibrated
000 - -
Freeze Frame:
Fault Status: 01100000
Fault Priority: 2
Fault Frequency: 1
Reset counter: 143
Time Indication: 0


-------------------------------------------------------------------------------
Address 72: Door, Rear Right (J389) Labels: None
Part No SW: 8X0 959 795 C HW: 8X0 959 795 C
Component: TSG HR H07 0415
Revision: -------- Serial number: --------------
Coding: 010E02200000000000
Shop #: WSC 00049 770 00153
VCID: 4FAD95B71E28F7665D9-801A

No fault code found.

End ---------------------------------------------------------------------

1 - 20 of 121 Posts
Top
